Vortex AMG 1-10x24 FFPEBR-9 MRAD
Vortex AMG 1-10x24 FFPEBR-9 MRAD
Regular price
$7,600.00 AUD
Regular price
$8,000.00 AUD
Sale price
$7,600.00 AUD
Unit price
per
Tax included.
Couldn't load pickup availability
Born from the demands of the world’s most elite operators, the AMG® 1-10x24 was conceived to meet a standard that didn’t exist, until now. Compact enough to run on carbines fully equipped with thermal attachments, lasers, red dots, and backup irons. Tough enough to survive what crushed everything else. Patented internals and structural innovations, every ounce engineered with purpose for those who’ve outgrown everything else.
AMG 1-10x24 FFP Dimensions (in inches)
| Lengths | |||||
|---|---|---|---|---|---|
| L1 | L2 | L3 | L4 | L5 | L6 |
| 8.4 | 1.97 | 1.12 | 4.86 | 0.38 | 3.20 |
| Heights | |
|---|---|
| H1 | H2 |
| 1.33 | 1.74 |
Specifications:
| Magnification | 1-10x |
|---|---|
| Objective Lens Diameter | 24 mm |
| Focal Plane | First Focal Plane |
| Reticle | EBR-9 (MRAD) |
| Eye Relief | 3.3" |
| Field of View | 116.0' - 12.0' @ 100 yds. |
| Turret Style | Dual Zero - Capped |
| Tube Size | 34mm |
| Adjustment Graduation | .1 MRAD |
| Travel Per Rotation | 10 MRAD |
| Max Elevation Adjustment | 30 MRAD |
| Max Windage Adjustment | 30 MRAD |
| Parallax Setting | 250 yds |
| Length | 8.4" |
| Weight | 18.8 oz. |
Features:
| Class Leading HD Optical System | Delivers high resolution and a wide field of view for advanced visual performance. |
| Dual Zero Turrets | Allows quick switching between different zero settings for varied shooting setups. |
| Toolless Turrets | Enables fast zeroing without tools with precise and reliable adjustments. |
| Compact and Lightweight | Measures 8.4 inches and fits short carbines while freeing rail space for accessories. |
| Integrated Throw Lever | Provides fast magnification changes with a low profile design to avoid snags. |
| APO Apochromatic System | Corrects color across the full spectrum for improved clarity and accuracy. |
| XR Plus Lens Coatings | Maximizes light transmission and clarity with advanced anti reflective coatings. |
| Locking Fast Focus Diopter | Maintains sharp reticle focus with a secure locking mechanism. |
| Plasma Tech Coating | Enhances coating durability and performance with advanced application technology. |
| Glass Etched Reticle | Offers precise reticle design protected between glass layers for durability. |
| Aircraft Grade Aluminum | Built from a solid block for strong, rigid, and durable construction. |
| ArmorTek Coating | Protects exterior lenses from scratches, oil, and dirt with a hard coating. |
| Low Glare Matte Black Anodize | Reduces glare and resists corrosion and wear for long term use. |
| Locking Side Illumination | Provides easy access with multiple brightness levels and secure locking control. |
| Argon Gas Purged | Ensures fogproof and waterproof performance in extreme conditions. |
| Made in USA with US and Global Parts | Engineered and assembled with precision for high quality performance. |
| Waterproof | Performs reliably in harsh and wet weather conditions. |
| Fogproof | Maintains clear visibility across varying temperature ranges. |
| Shockproof | Withstands heavy recoil and impact without loss of performance. |
Reticle:
EBR-9 (MRAD)
Designed for use in close-quarters and long-range shooting, the EBR-9 reticle can be used to effectively determine ranges, holdovers, and windage corrections.
