Vortex Spitfire HD Gen II 5x Prism AR-BDC4 (MOA)
Vortex Spitfire HD Gen II 5x Prism AR-BDC4 (MOA)
Couldn't load pickup availability
For shooters who need more reach without sacrificing speed, the Spitfire™ HD Gen II is built to excel at mid-range engagements. Its fixed magnification delivers sharp, accurate shots with its etched-glass reticle that stays visible even without illumination. Rugged, reliable, and ready for action, it’s uniquely designed for those who need an ideal balance of close-quarters speed and extended-range accuracy.
The Spitfire™ HD Gen II 5x model comes equipped with an MRDS mounting platform for use with Vortex® Viper® or Venom® MRDS.
Specifications:
| Dot Color | Bright Red |
|---|---|
| Battery Type | CR2032 |
| Magnification | 5x |
| Objective Lens Diameter | 25 mm |
| Reticle | AR-BDC4 |
| Eye Relief | 2.7" |
| Field of View | 23.3' @ 100 yds |
| Mount Type | Multi-Height |
| Adjustment Graduation | 1 MOA |
| Max Elevation Adjustment | 200 MOA |
| Max Windage Adjustment | 200 MOA |
| Parallax Setting | 100 yds. |
| Length | 3.6" |
| Weight | 10.3 oz. |
Features:
| HD Optical System | Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration, and provide outstanding color fidelity, edge-to-edge sharpness, and light transmission. |
|---|---|
| Fully Multi-Coated Lenses | Anti-reflective coatings on all air-to-glass surfaces provide increased light transmission for greater clarity and low-light performance. |
| Nitrogen Gas Purged | Gas purged and O-ring sealed for fogproof and waterproof performance in all conditions. |
| Micro Red Dot Sight Mounting Platform | Compatible with Viper®/Venom® Footprint. |
| Multi-Height Mount System | Lower 1/3 Co-Witness Mount and Low Mount. |
| 14-Hour Auto-Shutoff | Automatically shuts off after 14 hours of inactivity to save battery life. |
| Low-Glare Matte Black Anodized | Corrosion and wear resistant anodization provides low-glare matte surface and helps camouflage the shooter's position. |
| Night-Vision Compatibility | The lowest 2 settings are night-vision compatible. |
| 10 Daylight Bright Brightness Settings | Daylight bright, illuminated reticle aids in faster center-point acquisition in bright daylight conditions. |
| Waterproof | Designed to withstand harsh weather conditions. |
| Fogproof | Designed to withstand a wide range of temperatures. |
| Shockproof | Designed to withstand the highest levels of recoil and impact. |
Reticle:
This BDC reticle is built to get the most out of the 5.56 cartridge in your AR, providing both rapid target acquisition and the tools for holdovers out to 650 yards.
